优质冷轧钢板机柜IBM

IBM机柜系列 主要性能 The main performance


◆ 符合ANSI/EIA RS-310-D、 IEC297-2、 DIN41491; PART1、DIN41494。◆  PART7、GB/T3047.2-92标准；兼容ETSI标准。◆  材料：SPCC优质冷轧钢板，九折型材制造；◆  防护等级：IP20。◆  承载：静载1000KG。◆  高密度网孔的前门和后门设计可为服务器和联网设备提供充足的散热条件，又有效的解决了设备保护问题，且外型美观。◆  机柜顶部独特的开口设计为您提供充足的线缆进山通道，方便用户进行敷设和管理。◆  内部空间客户可根据自身需要，对托盘进行自由调整。◆  先进的线圈设计，方便客户对大量数据线缆进行管理和操作。◆  方便拆卸和锁定的左右侧门为用户安装及多个柜体的并柜使用提供方便。◆  柜体对“U”的准确位置，有显著标记。◆ 柜体内部为方便用户，多处设计有接地柱。◆  先进的设计理念，保证外观高贵典雅，型材焊接框架，使其结构稳固。
◆  In accordance with ANSI/EIA RS-310-D, IEC297-2, DIN41491; PART1, DIN41494, PART7,GB/T3047.2-92 standard and compatible to ETSI standard.◆  Material: SPCC high-quality cold steel rolling plates. ◆  Grade of Protection: IP20. ◆  Load: stationary load steel rolling plates. ◆  The design of the front and back door with the high-density openings can provide adequate heat dissipation conditions for server and networking equipments, and can also solve the problems of equipments protection, besides, it is elegant in appearance. ◆ The special opening design on the top of the cabinet to lay and manage. ◆  Customers can adjust the stock freely in order to meet their requirement for the inner space. ◆  Advanced coil design makes it convenient for customers to manage and operate the massive data cables. ◆ The left and right doors which are easy to mount and dismount makes it convenient for mounting and combining usage of several cabinets. ◆ The cabinet has outstanding mark for the precise position of “U”. ◆ Several earthing rod are set in the inner cabinet to provide convenient for users. ◆ Advanced design concept assures elegant appearance and the section bar lead frame makes the structure more stable.
